This product is no longer available
Please see below for documents and specifications related to this product
Sharp MX-C407F
Offering print speeds of up to 38ppm and scan speeds of up to 56ipm, productivity stays high and your data is printed or captured in no time at all, and available to you to distribute via your network, cloud or applications. Mobile printing is fully supported by AirPrint and Google Cloud Print, while the optional wireless LAN enables your device to be positioned anywhere within the office.
With industry leading security features you can be sure that your data both printed and electronic is safe and secure. Easy connectivity to the cloud, applications and workflows means that you can securely and easily access your data and distribute with speed, ease and peace of mind.
True 1200 x 1200dpi print quality, maximum paper capacity of 2,300 sheets and long life consumables giving low user intervention means the MX-C407F can effortlessly take care of your colour print requirements in-house and the 7" colour LCD touchscreen with Sharp Easy UI mode gives users an intuitive experience meaning even the most complex of processes are made simple.
The energy management features that reduce power consumption in both active and sleep mode, all help cut costs while being environmentally responsible at the same time.
Key features
- Print, Copy, Scan, Fax, File
- Pages per minute: 38 B/W, 38 Colour
- Paper capacity: Std 650 Max 2300 sheets
- 7" colour LCD touchscreen with Sharp Easy UI mode
- Mobile printing is fully supported
- Optional wireless LAN
- Industry leading security features
- Energy management features that reduce power consumption in both active and sleep mode
Sharp MX-C407F
The MX-C407F is a 4-in-1 A4 colour MFP that offers a host of productivity features that suits the needs of a small workgroup and mid or large offices.
| Function | Print, Copy, Scan, Fax, File |
| Colour or Black & White | Colour |
| Engine speed: A4 Colour (ppm) | 38 |
| Engine speed: A4 B/W (ppm) | 38 |
| Paper size: Min. | A6 |
| Paper size: Max. | A4 |
| Paper weight: Min. (g/m²) | 60 |
| Paper weight: Max. (g/m²) | 218 |
| Paper capacity: Std. (sheets) | 650 |
| Paper capacity: Max. (sheets) | 2300 |
| Memory general: Min. (GB) | 2 |
| Memory general: Max. (GB) | 4 |
| Storage: Opt. | HDD |
| HDD capacity: Opt. (GB) | 500 |
| Duplex | Std. |
| Power requirements: frequency min. (Hz) | 50 |
| Power requirements: frequency max. (Hz) | 60 |
| Power Requirements: voltage min. (V) | 220 |
| Power Requirements: voltage max. (V) | 240 |
| Power consumption (kW) | 1.84 |
| Base Unit: Width (mm) | 505 |
| Base Unit: Depth (mm) | 533 |
| Base Unit: Height (mm) | 648 |
| Weight (kg) | 45 |
| Network printer | Std. |
| Resolution (dpi) | 1200 x 1200 |
| Interface: Std. | USB 2.0, 10Base-T, 100Base-TX, 1000Base-T |
| Supported OS: Std. | Windows 7, Windows 8.1, Windows 10, Windows Server 2008, Windows Server 2008R2, Windows Server 2012R2, Windows Server 2016, Windows Server 2019, Mac OS X 10.6, Mac OS X 10.7, Mac OS X 10.8, Mac OS X 10.9, Mac OS X 10.10, Mac OS X 10.11 |
| Network protocols | TCP/IP (IPv4, IPv6), EtherTalk (AppleTalk), TCP, UDP, IPSEC, ICM, IGMP, 802.1x |
| Printing protocols | LPD, Raw TCP (port 9100), Enhanced IP (port 9400), FTP for downloading print files, TFTP, IPP |
| PDL: Std. | PCL5c, PCL6 emulation, Adobe® PostScript® 3™ emulation, XPS |
| Available Fonts | 89 PCL, 165 PostScript 3 |
| Original paper size: Max. | A4 |
| First copy out time: Colour (sec.) | 8 |
| First copy out time: B/W (sec.) | 7 |
| E-sort | Opt. |
| Continuous copy (Max. copies) | 9999 |
| Scan resolution: B/W (dpi) | 600 x 600 |
| Scan resolution: Colour (dpi) | 600 x 600 |
| Zoom range: Min. (%) | 25 |
| Zoom range: Max. (%) | 400 |
| Preset copy ratios | 6 |
| Network scanner | Std. |
| Scan method | Push scan, Pull scan |
| Push scan resolution (dpi) | 75, 150, 200, 300, 400, 600 |
| Pull scan resolution (dpi) | 75, 150, 200, 300, 400, 600 |
| File formats: Std. | XPS, TIFF, Compact PDF, PDF/A-1a, PDF/A-1b, BMP, Encrypted PDF, Searchable PDF, PDF, JPEG |
| Scan destinations | Desktop, FTP, Email, Network folder, USB |
| Document feeder capacity (sheets) | 50 |
| Fax | Std. |
| Compression method | MH, MR, MMR, JBIG, JBIG2, JPEG |
| Communication protocol | Super G3, G3 |
| Transmission time (sec.) | 2 |
| Modem speed: Min. (bps) | 2400 |
| Modem speed: Max. (bps) | 33600 |
| Transmission resolution: Std (dpi) | 203.2 x 97.8 dpi |
| Transmission resolution: Ultra Fine (dpi) | 406.4 x 391 dpi |
| Document size: Min. | A6 |
| Document size: Max. | A4 |
| Memory: Max. (MB) | 18 |
| Document filing | Std. |
| Confidential storage | No |
| Finishing | Available |
| Output capacity: Max. (sheets) | 50 |
| Wireless LAN | Opt. |
| Compliant regulation | IEEE802.11a/ac/b/g/n |
| Access mode | Infrastructure mode, WiFi Direct |
| Security | WEP, WPA2 PSK, WPA2 EAP |
| Black (pages at 5% coverage) | 20000 |
| Cyan (pages at 5% coverage) | 13000 |
| Magenta (pages at 5% coverage) | 13000 |
| Yellow (pages at 5% coverage) | 13000 |
Sharp MX-C407F
The MX-C407F is a 4-in-1 A4 colour MFP that offers a host of productivity features that suits the needs of a small workgroup and mid or large offices.
PS Printer-Driver for Windows, version 3.0.0.0, WIN32/64
Postscript Printer-Driver for Windows 7/8.1/10/7 x64/8.1 x64/10 x64/11, Windows Server 2008/2008 x64/2008 R2/2012 R2/2016/2019 with WHQL, version 3.0.0.0, production run date 11/03/2022, Multilanguage
23.03.2022
PCL6(XL) Printer-Driver for Windows, version 3.0.0.0, WIN32/64
PCL6(XL) Printer-Driver for Windows 7/8.1/10/7 x64/8.1 x64/10 x64/11, Windows Server 2008/2008 x64/2008 R2/2012 R2/2016/2019 with WHQL, version 3.0.0.0, production run date 11/03/2022, Multilanguage
23.03.2022
PCL5 Printer-Driver for Windows, version 3.0.0.0, WIN32/64
PCL5 Printer-Driver for Windows 7/8.1/10/7 x64/8.1 x64/10 x64/11, Windows Server 2008/2008 x64/2008 R2/2012 R2/2016/2019 with WHQL, version 3.0.0.0, production run date 11/03/2022, Multilanguage
23.03.2022
PS/PPD Printer-Driver for MacOS X 10.14-10.15/11, Version 2108a
PostscriptPPD Printer-Driver for MacOS X 10.14-10.15/11, version 2108a, production run date 31/08/2021, Multilanguage
22.10.2021
PS/PPD Printer-Driver for MacOS X 10.12 – 10.15
PostscriptPPD Printer-Driver for MacOS X 10.12 – 10.15, version 1.0.0.0, production run date 17/07/2020, Multilanguage
22.10.2021
PS Printer-Driver for Linux, version 1.0
Postscript Printer-Driver for Linux, version 1.0, production run date 05/12/2019, Multilanguage
22.10.2021
Network and local SANE scan driver for Linux, version 1.0.0.0
Network and local SANE scan driver for Linux, version 1.0.0.0, production run date 14/02/2020, Multilanguage
22.10.2021
Phone Book for Windows, version 02.06.00.00, WIN32/64
Phone Book for Windows 7/8.1/10/7 x64/8.1 x64/10 x64, Windows Server 2008/2008 x64/2008 R2/2012 R2/2016/2019, version 02.06.00.00, production run date 05/03/2020, Multilanguage
22.10.2021
TWAIN Scanner-Driver for Windows, version 01.19.168.00, WIN 32/64
TWAIN Scanner-Driver for Windows 7/8.1/10/7 x64/8.1 x64/10 x64, Windows Server 2008/2008 x64/2008 R2/2012 R2/2016/2019 with WHQL, version 01.19.168.00, production run date 05/03/2020, Multilanguage
22.10.2021
PCFax-Driver for Windows, version 02.14.04.00, WIN32/64
PCFax-Driver for Windows 7/8.1/10/7 x64/8.1 x64/10 x64, Windows Server 2008/2008 x64/2008 R2/2012 R2/2016/2019, version 02.14.04.00, production run date 05/03/2020, Multilanguage
22.10.2021
Sharp MX-C407F
The MX-C407F is a 4-in-1 A4 colour MFP that offers a host of productivity features that suits the needs of a small workgroup and mid or large offices.
Operation Manual
Operation Manual for MX-C407F, MX-C507F, all Languages
14.02.2022
